DJI Matrice 30 Series
DJI Matrice 30 Series
The M30 offers a balance of power and portability, resulting in higher operational efficiency. The M30 is equipped with IP55 protection, allowing it to withstand harsh weather conditions and temperatures ranging from -20°C to 50°C. To ensure safety during missions, the aircraft is equipped with dual-vision and ToF sensors on all six sides.
Additionally, the built-in ADS-B receiver provides timely warnings of any nearby crewed aircraft. Built-in redundancy systems ensure mission continuity even in unexpected scenarios. OcuSync 3 Enterprise is supported by four built-in antennas, allowing for triple-channel 1080p video transmission and seamless swapping between input feeds, even in complex environments.
The M30 Series is compact, foldable, and easy to pack, carry, and deploy. It integrates wide, zoom, and thermal cameras (M30T only) with a laser rangefinder, allowing you to capture the aerial data you need quickly and efficiently. The FPV camera is optimized for low-light conditions, providing clear visibility of the ground and skyline even at night, ensuring safe and confident flying.
Capture clear images in low-light conditions with Smart Low-Light Photo and detect hotspots and heat signatures with high-resolution thermal capabilities. Pinpoint an object in view and receive its coordinates through advanced sensor fusion algorithms.
Feature | Specification |
---|---|
Aircraft Dimensions (Unfolded) | 470×585×215 mm (L×W×H) |
Dimensions (Folded) | 365×215×195 mm (L×W×H) |
Diagonal Wheelbase | 668 mm |
Weight (incl. two batteries) | 3770 ± 10 g |
Max Takeoff Weight | 4069 g |
Max Takeoff Weight for C2 Certification (EU) | 3998 g |
Operation Frequency | 2.4000-2.4835 GHz; 5.725-5.850 GHz |
Transmitter Power (EIRP) | 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE) |
Hovering Accuracy | Vertical: ±0.1 m (Vision System enabled); ±0.5 m (N-mode with GPS); ±0.1 m (RTK) Horizontal: ±0.3 m (Vision System enabled); ±1.5 m (N-mode with GPS); ±0.1 m (RTK) |
RTK Positioning Accuracy | Horizontal: 1 cm + 1 ppm Vertical: 1.5 cm + 1 ppm |
Max Angular Velocity | Pitch: 150°/sec.; Yaw: 100°/sec. |
Max Pitch Angle | 35° (N-mode and Forward Vision System enabled: 25°) |
Max Ascent/Descent Speed | 6 m/s, 5 m/s |
Max Tilt Descent Speed | 7 m/s |
Max Horizontal Speed | 23 m/s |
Max Service Ceiling Above Sea Level (without other payload) | 5,000 m (with 1671 propellers) 7,000 m (with 1676 propellers) |
Max Wind Resistance | 12 m/s |
Max Hover Time | 36 min |
Max Flight Time | 41 min |
